Note: For use on 416, 417, 427 and 517 spelter sockets only
100% termination efficiency.
Temperature operating range is -65° F to +240° F (-54°C to +116°C). • Ideal for on-site applications.
No hazardous molten metal.
Improved fatigue life.
Pouring temperature without booster pack is 48° F to 110° F (6.67°C to 43.3°C).
One booster pack if pouring temperature is 35° F to 48° F (1.67°C to 8.89°C).
Two booster packs if pouring temperature is 27° F to 35° F (-2.78°C to +1.67°C).
Refer to Crosby® Wire Rope End Terminations Manual for more information.
Storage temperature is 68° F (20°C) max. Store in well ventilated area away from sunlight and sources of ignition.
Advantages:
● Lloyds Register of Shipping
● Det Norske Veritas (DNV)
● United States Coast Guard
● Registro Italiano Navale
● Germanischer Lloyd
● United States Navy
● American Bureau of Shipping
● ISO 17.558
● DNV-OS-E304
W416-7 Kits | Booster Pak Stock No. | |||
Kit Size | Kit Per Case | Stock No. | Weight Each (lbs.) | |
100 | 20 | 1039602 | .62 | 1039603 |
250 | 12 | 1039604 | 1.25 | 1039605 |
500 | 12 | 1039606 | 2.54 | 1039607 |
1000 | 12 | 1039608 | 4.59 | 1039609 |
2000 | 12 | 1039610 | 9.00 | 1039611 |
Guide to amount of WIRELOCK® Required
Wire Rope Size | WIRELOCK® Required (cc) | Wire Rope Size | WIRELOCK® (cc) | ||
(in.) | (mm) | (in.) | (mm) | ||
1/4 | 6-7 | 9 | 1-3/4 | 44 | 700 |
5/16 | 8 | 17 | 1-7/8 | 48 | 700 |
3/8 | 9-10 | 17 | 2 | 51 | 1265 |
7/16 | 11 | 35 | 2-1/8 | 54 | 1265 |
1/2 | 13 | 35 | 2-1/4 | 56 | 1410 |
9/16 | 14 | 52 | 2-3/8 | 60 | 1410 |
5/8 | 16 | 52 | 2-1/2 | 64 | 1830 |
3/4 | 20 | 86 | 2-5/8 | 67 | 1830 |
7/8 | 22 | 125 | 2-3/4 | 70 | 2250 |
1 | 26 | 160 | 3 | 76 | 3160 |
1-1/8 | 28 | 210 | 3-1/4 | 82 | 3795 |
1-1/4 | 32 | 350 | 3-1/2 | 88 | 4920 |
1-3/8 | 36 | 350 | 3-3/4 | 94 | 5980 |
1-1/2 | 40 | 420 | 4 | 102 | 7730 |
1-5/8 | 42 | 495 | — | — | — |
